Celli

power harrows

Tractors from 40 - 250 hp

Celli's fixed-width power harrows range in size from 1 m, for tight spaces, to 4.5 m, and suit tractors from 40 to 250 hp. Extra rotors, in combination with vertical, sliding side plates that contain the soil as it's worked, produce a finer seedbed.

Overview

  1. Fully welded gearbed to give greater rigidity and ensure gears stay “true at all times”
  2. 15 degree rotor timing to reduce horsepower demand and fuel consumption, producing a finer seedbed
  3. Boron steel tines
  4. Forged and heat treated one piece rotor shafts
  5. Greasable top bearings to ensure they have adequate lubrication
  6. 45 degree moving side plates to ensure flat finish for seedbed preparation
  7. Hardened gears for long life


warranty

Gallery


Features

Fully welded gearbed

Fully welded gearbed

Greasable top bearings

Greasable top bearings

45 degree sliding side plates ensure a flat seedbed finish

45 degree sliding side plates ensure a flat seedbed finish

Wide spaced bearings on rotors

Wide spaced bearings on rotors

15<sup>o</sup> rotor timing

15o rotor timing

Optional cone shaped rotor protectors for complete seal and bearing protection from stones, wire and foreign material

Optional cone shaped rotor protectors for complete seal and bearing protection from stones, wire and foreign material

Models

Models Working widths (cm) hp rating (max) Fact Sheet
Mini go 100, 125, 150, 175 80 Download
Go 150, 175, 200, 225, 250, 300 100 Download
Ranger 200, 225, 250, 300 130 Download
Energy 250, 300, 350, 400 200 Download
Maxi 300, 350, 400, 450 250 Download

Options

Cage roller  Oil cooler
Packer roller Quick fit tines
Customised rollers (tyre, rubber, cracker packer) 400 mm long potato tines
Hydraulic depth adjustment Tungsten coated tines
Cam clutch Preventative maintenance and three year warranty is optional
Rotor protectors

Parts Manuals

RANGER (after 2014)
RANGER (after 2014)
Download

8.4 MB (8,366,102.00 bytes)

RANGER (before 2006)
RANGER (before 2006)
Download

3 MB (3,036,376.00 bytes)

ENERGY (2003-2005)
ENERGY (2003-2005)
Download

3.9 MB (3,873,438.00 bytes)

ENERGY (2006-2009)
ENERGY (2006-2009)
Download

2.9 MB (2,850,504.00 bytes)

ENERGY (after 2010)
ENERGY (after 2010)
Download

3.2 MB (3,176,258.00 bytes)

ENERGY (before 2003)
ENERGY (before 2003)
Download

2.1 MB (2,149,400.00 bytes)

RANGER (2006-2010)
RANGER (2006-2010)
Download

3.3 MB (3,283,092.00 bytes)

MAXI (2002-2011)
MAXI (2002-2011)
Download

3.1 MB (3,085,426.00 bytes)

LASER
LASER
Download

2.7 MB (2,704,324.00 bytes)

RANGER (2011-2013)
RANGER (2011-2013)
Download

3.8 MB (3,835,970.00 bytes)

MAXI (after 2011)
MAXI (after 2011)
Download

6.7 MB (6,729,412.00 bytes)
